| def initiate(self, measurement):
"""
Create track from unassociated measurement.
Args:
measurement (ndarray): Bounding box coordinates (x, y, a, h) with
center position (x, y), aspect ratio a, and height h.
Returns:
The mean vector (8 dimensional) and covariance matrix (8x8
dimensional) of the new track. Unobserved velocities are
initialized to 0 mean.
"""
mean_pos = measurement
mean_vel = np.zeros_like(mean_pos)
mean = np.r_[mean_pos, mean_vel]
std = [
2 * self._std_weight_position * measurement[3],
2 * self._std_weight_position * measurement[3], 1e-2,
2 * self._std_weight_position * measurement[3],
10 * self._std_weight_velocity * measurement[3],
10 * self._std_weight_velocity * measurement[3], 1e-5,
10 * self._std_weight_velocity * measurement[3]
]
covariance = np.diag(np.square(std))
return mean, covariance
def predict(self, mean, covariance):
"""
Run Kalman filter prediction step.
Args:
mean (ndarray): The 8 dimensional mean vector of the object state
at the previous time step.
covariance (ndarray): The 8x8 dimensional covariance matrix of the
object state at the previous time step.
Returns:
The mean vector and covariance matrix of the predicted state.
Unobserved velocities are initialized to 0 mean.
"""
std_pos = [
self._std_weight_position * mean[3], self._std_weight_position *
mean[3], 1e-2, self._std_weight_position * mean[3]
]
std_vel = [
self._std_weight_velocity * mean[3], self._std_weight_velocity *
mean[3], 1e-5, self._std_weight_velocity * mean[3]
]
motion_cov = np.diag(np.square(np.r_[std_pos, std_vel]))
mean = np.dot(mean, self._motion_mat.T)
covariance = np.linalg.multi_dot(
(self._motion_mat, covariance, self._motion_mat.T)) + motion_cov
return mean, covariance
def project(self, mean, covariance):
"""
Project state distribution to measurement space.
Args
mean (ndarray): The state's mean vector (8 dimensional array).
covariance (ndarray): The state's covariance matrix (8x8 dimensional).
Returns:
The projected mean and covariance matrix of the given state estimate.
"""
std = [
self._std_weight_position * mean[3], self._std_weight_position *
mean[3], 1e-1, self._std_weight_position * mean[3]
]
innovation_cov = np.diag(np.square(std))
mean = np.dot(self._update_mat, mean)
covariance = np.linalg.multi_dot((self._update_mat, covariance,
self._update_mat.T))
return mean, covariance + innovation_cov
def multi_predict(self, mean, covariance):
"""
Run Kalman filter prediction step (Vectorized version).
Args:
mean (ndarray): The Nx8 dimensional mean matrix of the object states
at the previous time step.
covariance (ndarray): The Nx8x8 dimensional covariance matrics of the
object states at the previous time step.
Returns:
The mean vector and covariance matrix of the predicted state.
Unobserved velocities are initialized to 0 mean.
"""
std_pos = [
self._std_weight_position * mean[:, 3], self._std_weight_position *
mean[:, 3], 1e-2 * np.ones_like(mean[:, 3]),
self._std_weight_position * mean[:, 3]
]
std_vel = [
self._std_weight_velocity * mean[:, 3], self._std_weight_velocity *
mean[:, 3], 1e-5 * np.ones_like(mean[:, 3]),
self._std_weight_velocity * mean[:, 3]
]
sqr = np.square(np.r_[std_pos, std_vel]).T
motion_cov = []
for i in range(len(mean)):
motion_cov.append(np.diag(sqr[i]))
motion_cov = np.asarray(motion_cov)
mean = np.dot(mean, self._motion_mat.T)
left = np.dot(self._motion_mat, covariance).transpose((1, 0, 2))
covariance = np.dot(left, self._motion_mat.T) + motion_cov
return mean, covariance
def update(self, mean, covariance, measurement):
"""
Run Kalman filter correction step.
Args:
mean (ndarray): The predicted state's mean vector (8 dimensional).
covariance (ndarray): The state's covariance matrix (8x8 dimensional).
measurement (ndarray): The 4 dimensional measurement vector
(x, y, a, h), where (x, y) is the center position, a the aspect
ratio, and h the height of the bounding box.
Returns:
The measurement-corrected state distribution.
"""
projected_mean, projected_cov = self.project(mean, covariance)
chol_factor, lower = scipy.linalg.cho_factor(
projected_cov, lower=True, check_finite=False)
kalman_gain = scipy.linalg.cho_solve(
(chol_factor, lower),
np.dot(covariance, self._update_mat.T).T,
check_finite=False).T
innovation = measurement - projected_mean
new_mean = mean + np.dot(innovation, kalman_gain.T)
new_covariance = covariance - np.linalg.multi_dot(
(kalman_gain, projected_cov, kalman_gain.T))
return new_mean, new_covariance
def gating_distance(self,
mean,
covariance,
measurements,
only_position=False,
metric='maha'):
"""
Compute gating distance between state distribution and measurements.
A suitable distance threshold can be obtained from `chi2inv95`. If
`only_position` is False, the chi-square distribution has 4 degrees of
freedom, otherwise 2.
Args:
mean (ndarray): Mean vector over the state distribution (8
dimensional).
covariance (ndarray): Covariance of the state distribution (8x8
dimensional).
measurements (ndarray): An Nx4 dimensional matrix of N measurements,
each in format (x, y, a, h) where (x, y) is the bounding box center
position, a the aspect ratio, and h the height.
only_position (Optional[bool]): If True, distance computation is
done with respect to the bounding box center position only.
metric (str): Metric type, 'gaussian' or 'maha'.
Returns
An array of length N, where the i-th element contains the squared
Mahalanobis distance between (mean, covariance) and `measurements[i]`.
"""
mean, covariance = self.project(mean, covariance)
if only_position:
mean, covariance = mean[:2], covariance[:2, :2]
measurements = measurements[:, :2]
d = measurements - mean
if metric == 'gaussian':
return np.sum(d * d, axis=1)
elif metric == 'maha':
cholesky_factor = np.linalg.cholesky(covariance)
z = scipy.linalg.solve_triangular(
cholesky_factor,
d.T,
lower=True,
check_finite=False,
overwrite_b=True)
squared_maha = np.sum(z * z, axis=0)
return squared_maha
else:
raise ValueError('invalid distance metric')
|
是指有n帧没有检测结果匹配上的track。
